Model NO.: ST-AC005
In the testing of wireless RF terminal products, antennas and antenna couplers are indispensable. Antenna couplers play a vital role in facilitating the transfer of energy between testing equipment and antennas. They ensure stable signal coupling, allowing for accurate measurement of antenna performance, such as gain and radiation patterns. By using antenna couplers, engineers can effectively test antennas of various wireless RF terminal products, ensuring reliable and consistent testing results crucial for product quality assurance.
antenna coupler`s parameter：
Outer Dimension | 130(W) × 106(D) × 17(H)mm |
Material | Aluminum |
Weight) | about 350g |
Frequency Range | 800 ~ 8500MHz |
Insertion Loss | 7 ~ 18dB |
VSWR | about< 1 : 2.2(type1.7) |
RF Connector | SMA(f) |
polarization mode | RHCP |
